Siemens Q230 Circuit Breaker, Mini, 30 A, 2 -Pole, 120/240 V, Fixed Trip, Plug Mounting

Molded case with non-interchangeable trip. Will replace American Switch, Westinghouse Type BR, Bryant, Challenger, Sylvania, Crouse-Hinds, Murray, Frank Adams, General Electric (full size only), General Switch, I-T-E, Gould, Montgomery Ward and Sears. UL listed. HACR rated. 120/240 VAC; 10,000 AIR. 1 in per pole (2 in total).

Unit: EA

MPN: Q230

UPC: 783643148383

• Actuator Type: Magnetic Thermal
• Current Rating: 30 A
• Dimensions: 3 in L x 3 in W x 2 in H
• Frame Type: QP
• Interrupt Rating: 10 kA
• Mounting Type: Plug
• Number of Phases: 1
• Number of Poles: 2
• Operating Frequency: 50/60 Hz
• Operating Temperature: 40 deg C
• Terminal Type: Lug
• Trip Type: Fixed
• Type: Mini
• Voltage Rating: 120/240 V
• Wire Size: 14 to 6 AWG
