GE | Our Item #:
MORG6526453
Model Number: THQL1120AFP2 - UPC : 783164652833
GE THQL1120AFP2 Circuit Breaker, AFCI, 20 A, 2-Pole, 120/240 V, Plug
$66.33
$76.35
Unit price
/
Unavailable
Shipping calculated at checkout.
13% off
GE THQL1120AFP2 Circuit Breaker, AFCI, 20 A, 2-Pole, 120/240 V, Plug is backordered and will ship as soon as it is back in stock.
Couldn't load pickup availability
Shipping Policy
Shipping Policy
Item ships in 1 to 2 business days. Choose your shipping option during checkout. Read our Shipping Policy and Return Policy.
GE THQL1120AFP2 Circuit Breaker, AFCI, 20 A, 2-Pole, 120/240 V, Plug
$66.33
$76.35
Unit price
/
Unavailable
Features
- Parallel protection - direct contact of two wires with opposite polarity
- Ground protection - arc between a single conductor and ground
- Series protection - arc across the break in a single conductor, which progresses to a ground or parallel arc
- Overload protection
- Short circuit protection
Description
Description
Provides ARC fault, parallel, ground, Series, overload and short circuit protection. Required for bedroom receptacles effective January 1, 2002. Plug in design with color-coded screws and dual function test button. 120/240 V. 1 in space per breaker.
Unit: EA
UPC: 783164700091
Model Number: THQL1120AF2A
Unit: EA
UPC: 783164700091
Model Number: THQL1120AF2A
Additional Information
Additional Information
- Actuator Type: Magnetic Thermal
- Current Rating: 20 A
- Dimensions: 3.28 in L x 1 in W x 2.38 in D
- Frame Type: Q-Line
- Interrupt Rating: 10 kA
- Mounting Type: Plug
- Number of Phases: 1
- Number of Poles: 2
- Operating Temperature: 60 or 70 deg C
- Terminal Type: Screw Clamp
- Type: AFCI
- Voltage Rating: 120/240 V
- Wire Size: 14 to 10 AWG
