Ge  |  Our Item #: MORG6122030

Model Number: THQL2130 - UPC : 783164012927

GE THQL2130 Feeder Circuit Breaker, Type THQL, 30 A, 2-Pole, 120/240 V, Non-Interchangeable Trip, Plug

$18.59 $21.45
Shipping calculated at checkout.
13% off

Shipping Policy

Item ships in 1 to 2 business days. Choose your shipping option during checkout. Read our Shipping Policy and Return Policy.

Features

  • Tin-plated copper stabs create a reliable, permanent and corrosion-resistant connections
  • Calibration screw is cemented to prevent shifting
  • Case is made of heat-resistant thermoset for stability and structural integrity
  • Trips to the center position

Description
Copper-to-copper connections, calibrated for optimum trip performance, heat-resistant thermoset cases and covers, cemented calibration screw. May be used, when marked to accept, with American Switch, Arrow Hart, Bryant, General Switch, GTE, Sylvania, most ITE, Murray, Westinghouse Type BR, Challenger, Crouse-Hinds. 15 to 30 A 14-8 Cu or 12-8 Al AWG wire, 35 to 60 A 8-3 Cu or 8-2 Al AWG wire, 70 to 100 A 6-1/0 Cu or 4-1/0 Al AWG wire. UL Listed, HACR rated. 120/240 V, 10,000 Air. 1 in per pole (2 in total).

Additional Information

  • Actuator Type: Quick-Make Quick-Break
  • Current Rating: 30 A
  • Dimensions: 3.28 in L x 2 in W x 2.38 in H
  • Frame Type: Q-Line
  • Interrupt Rating: 10 kA
  • Mounting Type: Plug
  • Number of Phases: 1
  • Number of Poles: 2
  • Operating Frequency: 50/60 Hz
  • Operating Temperature: 60 to 75 deg C
  • Suitable for: Reverse Feed
  • Terminal Type: Screw Clamp
  • Trip Type: Non-Interchangeable
  • Type: Type THQL
  • Voltage Rating: 120/240 V
  • Wire Size: 14 to 8 12 to 8 AWG
