Kwikset 200DNL 15RCLRCSBX Passage Lever, Non-Locking Lock, Satin Nickel, Zinc, Reversible Hand, Residential, 3 Grade

Kwikset Passage Lever, Non-Locking Lock, Satin Nickel, Zinc, Residential Commercial/Residential, Door Handing: Reversible, 3 Grade, 5-Pin Cylinder, 3-3/4 in Lever Length, 6-Way Adjustable Latch, 2-1/8 in Cross Bore Diameter, 1-3/8 to 1-3/4 in Door Thickness, 1 in Edge Bore Diameter, 1 x 2-1/4 in Faceplate, 1/2 in Throw Length, Projection: 2-1/8 in, 2-1/4 in Strike, Full Lip Round Corner Strike, Rose/Base Dimensions: 2-5/8 in
Unit: BX
UPC: 883351592253
Model Number: 200DNL156ALRCSV1

• Backset Size: 2-3/8 x 2-3/4 in
• Bolt Throw Size: 1/2 in
• Commercial/Residential: Residential
• Cross Bore Diameter: 2-1/8 in
• Cylinder Type: 5-Pin
• Door Handing: Reversible
• Door Thickness: 1-3/8 to 1-3/4 in
• Edge Bore Diameter: 1 in
• Faceplate Size: 1 x 2-1/4 in
• Finish: Satin Nickel
• Latch Type: 6-Way Adjustable
• Lever Length: 3-3/4 in
• Lock Type: Non-Locking
• Material: Zinc
• Projection Size: 2-1/8 in
• Rose/Base Dimensions: 2-5/8 in
• Security Grade: 3
• Strike Size: 2-1/4 in
• Strike Type: Full Lip Round Corner
• Throw Length: 1/2 in
