Eaton Wiring Devices | Our Item #:
MORG3396173
Model Number: CR20V - UPC : 032664489181
Eaton CR20V Duplex Receptacle, 2-Pole, 20 A, 125 V, Side Wiring, NEMA: 5-20R, Ivory
Get special pricing! Apply for a business account today.
Apply Now
Sale price
$3.16
Regular price
$4.49
Unit price
Unavailable
Shipping calculated at checkout.
30% off
Eaton CR20V Duplex Receptacle, 2-Pole, 20 A, 125 V, Side Wiring, NEMA: 5-20R, Ivory is backordered and will ship as soon as it is back in stock.
Shipping Policy
Shipping Policy
Item ships in 1 to 2 business days. Choose your shipping option during checkout. Read our Shipping Policy and Return Policy.
Eaton CR20V Duplex Receptacle, 2-Pole, 20 A, 125 V, Side Wiring, NE...
Sale price
$3.16
Regular price
$4.49
Unit price
Unavailable
Eaton Wiring Devices | Our Item #:
MORG3396173
Sale price
$3.16
Regular price
$4.49
Unit price
Unavailable
Shipping calculated at checkout.
Eaton CR20V Duplex Receptacle, 2-Pole, 20 A, 125 V, Side Wiring, NEMA: 5-20R, Ivory is backordered and will ship as soon as it is back in stock.
Features
- Sturdy, compact design meets the demands of commercial spec-grade performance
- Excellent plug blade retention provided by 0.032 in (0.81mm) triple wipe brass line contacts and 0.050 in (1.27mm) brass ground
- High-impact-and chemical-resistant nylon face
- 0.035 in galvanized steel, wraparound yoke mounting strap for great assembly security, extra length/width helps reach large panel cutouts for code compliance
- Automatic grounding system eliminates need for bonding jumper in grounded metal enclosure and provides redundant measure of ground continuity where jumper is used
- Screw-catch feature on duplex devices speeds mounting of wallplates
- Tamper-resistant receptacle provide compliance with 2017 NEC Article 406.12 that states that all 15 A and 20 A
Description
Description
Commercial specification-grade straight blade receptacles - 20 A-125 V, NEMA 5-20R. Engineered for safe, reliable performance, these UL 498 and Federal Specification WC-596 listed devices provide maximum durability in a wide variety of applications while providing installation efficiency to help finish the job on time.
Unit: EA
UPC: 032664489181
Model Number: CR20V
Unit: EA
UPC: 032664489181
Model Number: CR20V
Additional Information
Additional Information
- Color: Ivory
- Current Rating: 20 A
- Dimensions: 4 in L x 1.24 in W x 0.79 in D
- Frequency Rating: 60 Hz
- Material: PVC
- Mounting Type: Wall
- NEMA Configuration: 5-20R
- Number of Poles: 2
- Number Of Wires: 3
- Operating Temperature: -20 to 60 deg C
- Voltage Rating: 125 V
- Wire Size: 14 to 10 AWG
- Wiring Type: Side
