ProSource 20338SNX Square Corner Door Hinge, Steel, Satin Nickel, Loose Pin, 180 deg Range of Motion

A creaking door at your place, don't get too worked up about it since there is a remedy to that. Those days of creaking or breaking hinges are over with this hinge - the door control hinge you need. It's great for interior and exterior applications. Suitable to use on all non-commercial interior, exterior doors or wood furniture, this corner hinge is the best. With this hinge, you are getting a high-quality fitting. This hinge can hold a light to medium weighted doors. You have to do very little maintenance. Overall, it s well with most types of doors and better with aluminum ones. Once installed, this hinge makes the opening of doors very easy.
Unit: BAG
UPC: 045734927131
Model Number: 20338SNX

• Color: Satin Nickel
• Dimensions: 3-1/2 x 3-1/2 in
• Door Leaf Height: 3-5/8 in
• Door Leaf Thickness: 2.2 mm
• Door Leaf Width: 1-1/2 in
• Door Thickness: 1-3/4 in
• Finish: Satin Nickel
• Hole Spacing: 1-1/2 in
• Includes: Screws
• Knuckle Diameter: 6.3 mm
• Knuckle Length: 24 mm
• Material: Steel
• Mounting Hole Diameter: 6 mm
• Mounting Type: Screw Mount
• Number of Knuckles: 5
• Number of Mounting Holes: 6
• Pin Diameter: 5.5 mm
• Pin Type: Loose
• Range of Motion: 180 deg

Application: For residential applications
