Wayne Water Systems  |  Our Item #: MACE4003742

Model Number: CDU800SS - UPC : 040066218902

Wayne 1/2 HP 5100 gph Stainless Steel Vertical Float Switch AC Sump Pump

Get special pricing! Apply for a business account today.

Apply Now
$224.24 $239.99
Shipping calculated at checkout.
7% off

Shipping Policy

Item ships in 1 to 2 business days. Choose your shipping option during checkout. Read our Shipping Policy and Return Policy.

Features

  • Brand Name:Wayne
  • Product Type: Sump Pump
  • Amps: 3.8 ampere
  • Brand Name: Wayne
  • Depth: 10 inch
  • Diameter: 12 inch
  • Height: 14 inch
  • Horsepower: 1/2 HP (horsepower)
  • Housing Material: Stainless Steel
  • Maximum Discharge Flow: 5100 gph
  • Maximum Temperature: 77 degree Fahrenheit
  • Minimum Temperature: 33 degree Fahrenheit
  • Pump Switch Type: Vertical Float Switch
  • Sump Pump Outlet Diameter: 1 1/2 inch
  • Volts: 120 volt
  • Width: 10 inch
  • Powered By: AC
  • Maximum Feet of Head: 20 foot
  • Intake: Top Suction
  • Agency Compliance: CSA and UL
  • Discharge Flow at 10 ft.: 3840 gph
  • Discharge Flow at 20 ft.: 2040 gph
  • Discharge Flow at 25 ft.: 3000 gph
  • Turn On/Off Level: 9 in./4 in.

    • Description
    Tested to 1 million cycles; For performance that lasts, Wayne Pumps exceeds an average life of 1 million cycles. Wayne Pumps' energy-efficient motors and engineered design provide the ultra-quiet experience you won't believe. Durable epoxy-coated and rugged cast iron construction, for long life in tough sump pump applications. High performance; max. flow rate is 5100 gallons per hour; 3840 GPH at 10 ft. of discharge lift. Integrated vertical float switch with solid, leak free polypropylene float for automatic operation; 9 in. On level and 4 in. Off level. No need for weep holes; unique top suction design reduces clogging and prevents air lock condition. Engineered with upper and lower ball bearings, in sealed oil bath, for virtually silent operation. Designed with premium john crane carbon/ceramic shaft seals for quality that lasts.
  • Cast iron seal plate prevents leaks and galvanic corrosion
  • 1-1/2 In. NPT discharge for compliance with building codes
  • Float guard, protects switch from hang-ups from debris and side of pit
  • Abrasion resistant glass reinforced polycarbonate impeller for reliability
  • 8 ft. water resistant power cord provides easy access to nearby GFCI protected outlet
  • For easy installation, use in 11 in. diameter or larger sump basins

    •
    California residents see  Prop 65 Warning(s)

    ⁠­
    UPC: 040066218902
    Model Number: CDU800SS
