Square D | Our Item #:
MORG6721393
Model Number: HOM270CP - UPC : 047569062810
Square D Homeline HOM270CP Circuit Breaker, Mini, 70 A, 2 -Pole, 120/240 V, Fixed Trip, Plug Mounting, Black
$50.96
$63.95
Unit price
/
Unavailable
Shipping calculated at checkout.
20% off
Square D Homeline HOM270CP Circuit Breaker, Mini, 70 A, 2 -Pole, 120/240 V, Fixed Trip, Plug Mounting, Black is backordered and will ship as soon as it is back in stock.
Couldn't load pickup availability
Shipping Policy
Shipping Policy
Item ships in 1 to 2 business days. Choose your shipping option during checkout. Read our Shipping Policy and Return Policy.
Square D Homeline HOM270CP Circuit Breaker, Mini, 70 A, 2 -Pole, 12...
$50.96
$63.95
Unit price
/
Unavailable
Features
- HOM one-pole standard circuit breakers (15 - 50 A)
- HOM two-pole standard circuit breakers (15 - 200 A)
- HOM tandem breakers (1-pole, 15/15 A, 20/20 A, 15/20 A, 20/30 A)
- HOM quad tandems circuit breakers (1- and 2-pole, 15 A to 50 A)
- HOM ground-fault circuit interrupters (1 and 2-pole, 15 - 50 A)
- Square D arc-fault circuit-interrupters (1-pole, 15 A and 20 A)
- Square D combination arc-fault circuit interrupters (1-pole, 15 A and 20 A)
- Available accessories include handle attachments, filler plates, and neutral lugs
- HOM sub-feed lugs, two-pole, rated 125 A and 225 A
Description
Description
Engineered for value, Homeline circuit breakers are designed for fast installation, reliability and great circuit protection. With industry leading innovations and exclusive features, Square D Homeline circuit breakers are the smart, safe, reliable choice.
Additional Information
Additional Information
- Color: Black
- Current Rating: 70 A
- Dimensions: 2 in W x 2.98 in D x 3.13 in H
- Interrupt Rating: 10 kA
- Mounting Type: Plug
- Number of Phases: 1
- Number of Poles: 2
- Number Of Spaces: 2
- Operating Frequency: 50/60 Hz
- Operating Temperature: 104 deg F
- Terminal Type: Lug
- Trip Sensitivity: 94.5 A
- Trip Type: Fixed
- Type: Mini
- Voltage Rating: 120/240 V
- Wire Size: 8 to 2 AWG
