Southwire | Our Item #:
MORG9269390
Model Number: 553036607 - UPC : 029892353940
CCI 553036607 Thermostat Wire, 18 AWG Wire, 3-Conductor, Copper Conductor, Polypropylene Insulation, PVC Sheath, 150 V
$122.00
$240.00
Unit price
/
Unavailable
Shipping calculated at checkout.
49% off
CCI 553036607 Thermostat Wire, 18 AWG Wire, 3-Conductor, Copper Conductor, Polypropylene Insulation, PVC Sheath, 150 V is backordered and will ship as soon as it is back in stock.
Couldn't load pickup availability
Shipping Policy
Shipping Policy
Item ships in 1 to 2 business days. Choose your shipping option during checkout. Read our Shipping Policy and Return Policy.
CCI 553036607 Thermostat Wire, 18 AWG Wire, 3-Conductor, Copper Con...
$122.00
$240.00
Unit price
/
Unavailable
Features
- This cable consists of three bare copper insulated conductors with an overall jacket
- Smooth jacket eliminates snagging and tearing
- PVC jacket, polypropylene insulation ensures excellent strip ability
- Sunlight resistant jacket
Description
Description
500 ft reel, 18 AWG conductor soft annealed solid copper per ASTM B3-90. PVC thermostatic insulation, temperature 60 deg C. Used for thermostat controls, heating and air conditioning installations, burglar alarm systems, intercom systems and doorbells. Type CL2, 150 V. PVC insulation UL13 for power limited circuit cable for other than plenum, riser or tray uses and UL1581 approved.
Unit: L FT
UPC: 029892353940
Model Number: 553036607
Unit: L FT
UPC: 029892353940
Model Number: 553036607
Additional Information
Additional Information
- Conductor Insulation: Polypropylene
- Conductor Material: Copper
- Number of Conductors: 3
- Operating Temperature: -20 to 60 deg C
- Resistance: 6.32 Ohm
- Sheath Color: Brown
- Sheath Material: PVC
- Stranded/Solid: Solid
- Type: Type CL-2
- Voltage Rating: 150 V
- Wire Size: 18 AWG
