Pass & Seymour/Legrand  |  Our Item #: MORG0254094

Model Number: 2087WCCD4 - UPC : 785007135817

Legrand radiant Series 2087WCCD4 GFCI Receptacle, 125 V, 20 A, NEMA: NEMA 5-20R, Back and Side Wiring, White

Get special pricing! Apply for a business account today.

Apply Now
$31.14 $43.45
Shipping calculated at checkout.
28% off

Shipping Policy

Item ships in 1 to 2 business days. Choose your shipping option during checkout. Read our Shipping Policy and Return Policy.

Features

  • Part of the radiant collection of wiring devices, wallplates and home systems
  • Rated as a 1-1/2 hp motor control switch
  • Thinner than competitors' GFCI Receptacles leaves more room for wires in the box
  • Auto-ground clip assures a positive ground to metal box
  • Feed-thru wiring configuration allows GFCI to protect downstream receptacles
  • Prevents line-load reversal miswire, no power to the face or downstream receptacles if wired incorrectly
  • Trip indicator light
  • Two back wire holes per terminal
  • Ground screw has a back wire clamp for easy installation
  • Mounting screws are shipped captive in the device and wallplate for easier installation

Description
The radiant collection is a step up from the standard with simple, classic options in wiring devices, home automation controls and screwless wallplates that complement today's homes and hospitality setting.
Unit: EA
UPC: 785007135817
Model Number: 2087WCCD4

Additional Information

  • Color: White
  • Current Rating: 20 A
  • Dimensions: 1.73 in W x 1.03 in D x 4.2 in H
  • Grounding Type: Grounded
  • Material: Thermoplastic
  • Mounting Type: Screw
  • Nema Rating: NEMA 5-20R
  • Number Of Wires: 3
  • Short Circuit Current Rating: 10 kA
  • Voltage Rating: 125 V
  • Wire Size: 14 to 10 AWG
  • Wiring Type: Back and Side
