Philips ICN2S40N Electronic Electronic Ballast, 120 - 277 VAC, 0.26 - 0.62 A, Rapid Start, 0.85 - 0.95 Ballast, 2 40 W

Advance Centium Lamp Ballast, Electronic, Series: ICN-2S40-N35M, 120/277 V, 72 W, 0.62 - 0.26 A, 50/60 Hz, Fluorescent Lamp, T12 Lamp Base, 40 W Lamp, 2 Lamps, 0.85, Rapid Start, >0.9, 10 - 50 deg F Minimum, NEMA 410 Enclosure, 25 deg F, 1 in Overall Height, 1.3 in Overall Width, 9-1/2 in Overall Length, Aluminum, White Painted, Maximum THD <10%
Unit: EA
UPC: 781087074879
Model Number: ICN2S40N

• Series: Advance, Centium
• Type: Electronic
• Voltage Rating: 120 - 277 VAC
• Wattage: 72
• Amperage Rating: 0.26 - 0.62 A
• Frequency Rating: 50/60 Hz
• Lighting Technology: Series
• Lamp Type: F40T12 Fluorescent, T12
• Lamp Base Type: T12
• Lamp Wattage: 40 W
• Number of Lamps: 2
• Ballast Factor: 0.85 - 0.95
• Start Type: Rapid
• Power Factor: 0.98
• Minimum Starting Temperature: 50 deg F
• Enclosure Type: NEMA 410
• Temperature Range: 70 deg C
• Overall Height: 1 in
• Overall Width: 1.31 in
• Overall Length: 9-1/2 in
• Material: Metal
• Finish: White Painted
• Includes: 36 in Violet and Gray Control Leads
• Standards: CE Certified, CSA Certified, UL Listed, RoHS Compliant
• Special Features: 18 AWG Solid Wire
• Usage: For Outdoor Applications
