Siemens Q120 Circuit Breaker, Mini, 20 A, 1 -Pole, 120/240 V, Fixed Trip, Plug Mounting

Non-interchangeable trip. 120 VAC, 10,000 AIR. Will replace American Switch, Westinghouse Type BR, Bryant, Challenger, Sylvania, Crouse-Hinds, Murray, Frank Adams, General Electric (Full size only), General Switch, I-TE, Gould, Montgomery Ward and Sears. UL listed, HACR rated. 15 and 20 A UL listed for frequent switching applications, 120 VAC fluorescent lighting. 1 in per pole.

Unit: EA

MPN: Q120

UPC: 783643148192

• Actuator Type: Magnetic Thermal
• Current Rating: 20 A
• Dimensions: 3.6 in L x 12.8 in W x 3.5 in H
• Frame Type: QP
• Interrupt Rating: 10 kA
• Mounting Type: Plug
• Number of Phases: 1
• Number of Poles: 1
• Operating Frequency: 50/60 Hz
• Operating Temperature: 40 deg C
• Terminal Type: Lug
• Trip Type: Fixed
• Type: Mini
• Voltage Rating: 120/240 V
• Wire Size: 14 to 8 AWG
