Ideal Industries Inc  |  Our Item #: MACE3025749

Model Number: 30-451P - UPC : 783250681266

Ideal Industries Wing-Nut Insulated Wire Connector Yellow 100 pk

$5.50 $9.99
Shipping calculated at checkout.
 More payment options

Shipping Policy

Item ships in 1 to 2 business days. Choose your shipping option during checkout. Read our Shipping Policy and Return Policy.

Features

  • Brand Name:Ideal
  • Sub Brand: Wing-Nut
  • Product Type: Wire Connector
  • Brand Name: Ideal
  • CSA LIsted: Yes
  • Color: Yellow
  • Number in Package: 100 pack
  • Packaging Type: Boxed
  • Sub Brand: Wing-Nut
  • UL Listed: Yes
  • Wire type: Insulated

    • Description
    The IDEAL Wing-Nut Wire Connector provides an easy, secure grip when connecting a wide range of wires. The specially designed contoured wings make for extra torque and quick work on any electrical job. The wide range, live-action spring is flexible enough to handle small combinations with ease but then expands to accept large combinations when you need it. It can also be reused on same size or larger combinations for quick and easy circuit changes and additions.
  • Copolymer shell expands for smooth, progressive tightening providing dependable connections
  • For use with #18 to #10 AWG copper conductors
  • Minimum wire range: 2 #18 AWG, maximum wire range: 3 #12 AWG
  • Rated to 600-Volt maximum, 1000-Volt signs and fixtures
  • Deep skirt helps protect against flash-over and turned-back strands for maximum dielectric protection
  • Tough UL 94-Volt-2 flame-retardant shell rated at 221F
  • UL Listed to 486C and CSA certified to C22.2 #188

    •   California residents see


    UPC: 783250681266
    Model Number: 30-451P

    Additional Information
    Ideal Industries Inc

    Ideal Industries Wing-Nut Insulated Wire Connector Yellow 100 pk

    $5.50 $9.99
    The IDEAL Wing-Nut Wire Connector provides an easy, secure grip when connecting a wide range of wires. The specially designed contoured wings make for extra torque and quick work on any electrical job. The wide range, live-action spring is flexible enough to handle small combinations with ease but then expands to accept large combinations when you need it. It can also be reused on same size or larger combinations for quick and easy circuit changes and additions.
  • Copolymer shell expands for smooth, progressive tightening providing dependable connections
  • For use with #18 to #10 AWG copper conductors
  • Minimum wire range: 2 #18 AWG, maximum wire range: 3 #12 AWG
  • Rated to 600-Volt maximum, 1000-Volt signs and fixtures
  • Deep skirt helps protect against flash-over and turned-back strands for maximum dielectric protection
  • Tough UL 94-Volt-2 flame-retardant shell rated at 221F
  • UL Listed to 486C and CSA certified to C22.2 #188

    •   California residents see


    UPC: 783250681266
    Model Number: 30-451P
