Diamond Products  |  Our Item #: MORG3259629

Model Number: 46904 - UPC : 603461469043

Diamond Products 46904 Tile Saw, 120 V, 6.6 A, 800 W, 9 in Dia Blade

$805.93 $926.89
Shipping calculated at checkout.

Shipping Policy

Item ships in 1 to 2 business days. Choose your shipping option during checkout. Read our Shipping Policy and Return Policy.

Features

  • Lightweight and compact for high-performance cutting
  • Heavy-duty table with measuring guide
  • Angle guide plate holds the work piece at various angles
  • Easily adjustable cutting guide remains parallel at all times
  • Easy mounting water tray
  • Safety relay switch
  • Quick-release, tool-free table mount release for easy cleaning and blade replacement
  • Easy adjustment miter - up to 45 deg

Description
Diamond Products Tile Saw, 120 V, 6.6 A, Frequency Rating: 50/60 Hz, Wattage Rating: 800 W, Ripping Capacity: 12 in Left, 5-25/32 in Right, 11-39/64 in Left at 45 deg Bevel, Cutting Capacity: 11-7/32 in Left, 10-13/16 in Left at 45 deg Bevel, 3000 to 3600 rpm, Cutting Depth: 1-7/8 in Straight, 1-7/16 in at 45 deg Bevel, Blade Diameter: 9 in, Control Type: Switch, Black/Orange/White, Dimensions: 10-1/2 in H x 26 in W x 20-1/2 in D, Includes: Parallel Cutting Guide, Angle Guide Plate, M8 Combination Wrench, M19 Combination Wrench

Additional Information

  • Blade Diameter: 9 in
  • Color: Black/Orange/White
  • Control Type: Switch
  • Current Rating: 6.6 A
  • Cutting Capacity: 11-7/32 in Left 10-13/16 in Left at 45 deg Bevel
  • Cutting Depth: 1-7/8 in Straight 1-7/16 in at 45 deg Bevel
  • Dimensions: 10-1/2 in H x 26 in W x 20-1/2 in D
  • Frequency Rating: 50/60 Hz
  • Includes: Parallel Cutting Guide Angle Guide Plate M8 Combination Wrench M19 Combination Wrench
  • Ripping Capacity: 12 in Left 5-25/32 in Right 11-39/64 in Left at 45 deg Bevel
  • Speed Rating: 3000 to 3600 rpm
  • Voltage Rating: 120 V
  • Wattage Rating: 800 W
