Model Number: LR-050-PS - UPC : 045734647442
ProSource LR-050-PS Cabinet Hinge of 2-1/2 in L x 1-3/4 in W, Steel, Zinc, Fixed Pin,180 deg Range of Motion, Full Mortise Mounting, 20 (Pair) lb
Get special pricing! Apply for a business account today.
Apply NowProSource LR-050-PS Cabinet Hinge of 2-1/2 in L x 1-3/4 in W, Steel, Zinc, Fixed Pin,180 deg Range of Motion, Full Mortise Mounting, 20 (Pair) lb is backordered and will ship as soon as it is back in stock.
Shipping Policy
Shipping Policy
Item ships in 1 to 2 business days. Choose your shipping option during checkout. Read our Shipping Policy and Return Policy.
ProSource LR-050-PS Cabinet Hinge of 2-1/2 in L x 1-3/4 in W, Steel...
ProSource LR-050-PS Cabinet Hinge of 2-1/2 in L x 1-3/4 in W, Steel, Zinc, Fixed Pin,180 deg Range of Motion, Full Mortise Mounting, 20 (Pair) lb is backordered and will ship as soon as it is back in stock.
Features
- Steel with zinc plated finish
- Square corner
- Three knuckles, non removable pin
- For general utility use on lightweight doors
Description
Description
Unit: CD 2
UPC: 045734647442
Model Number: LR-050-PS
Additional Information
Additional Information
- Color: Silver
- Dimensions: 2-1/2 in L x 1-3/4 in W
- Door Leaf Height: 1-11/16 in
- Door Leaf Thickness: 1.7 mm
- Door Leaf Width: 3/4 in
- Finish: Zinc
- Hole Spacing: 1 in
- Includes: Mounting Hardware
- Knuckle Length: 13 mm
- Material: Steel
- Mounting Hole Diameter: 5 mm
- Mounting Type: Full Mortise
- Number of Knuckles: 5
- Number of Mounting Holes: 6
- Pin Type: Fixed
- Range of Motion: 180 deg
- Suitable for: Lightweight Doors
- Weight Capacity: 20 (Pair) lb
